| مكان المنشأ: | هيبي |
|---|---|
| اسم العلامة التجارية: | Yuntong |
| إصدار الشهادات: | CE , SGS |
| رقم الموديل: | yt--f |
| الحد الأدنى لكمية: | 10 متر مربع |
| الأسعار: | USD 2-50 |
| تفاصيل التغليف: | حزمة فيلم لكل قطعة ، عدة قطع معبأة في 1 كرتون |
| وقت التسليم: | 5-8 أيام عمل |
| شروط الدفع: | / تي تي، ويسترن يونيون، بايبال |
| القدرة على العرض: | 300 متر مربع/أسبوع |
| اسم المنتج: | شبكة كابل X-tend | الكلمة الرئيسية: | المعاوضة الكابلات الفولاذ المقاوم للصدأ |
|---|---|---|---|
| مادة: | AISI316 ، AISI316L | حبل سلكي: | من 1.2 مم إلى 4.0 مم |
| إنشاءات الحبال السلكية: | 7 × 7 ، 7 × 19 ، 1 × 19 | انتهى: | حمام الموجات فوق الصوتية، أكسيد أسود |
| اتجاه شبكة: | أفقي ، عمودي | زاوية شبكة: | 60 درجة |
| إبراز: | acid-resistant bird cage,alkali-resistant zoo aesthetic cage,X Tend cable mesh bird enclosure,alkali-resistant zoo aesthetic cage,X Tend cable mesh bird enclosure |
||
Resistant To Acid And Alkali X Tend Cable Mesh Zoo Aesthetic Bird Cage
X Tend Cable Mesh is made of stainless steel wire. The material of the wire is stainless steel: 201.304, 304L, 316, 316L, etc. Hot and cold galvanized steel wire rope can also be used as required.Two conventional types of stainless steel rope mesh.
The x-tend cable mesh is manufactured in the standard diameters 1.0 mm, 1.5 mm, 1.6mm, 2.0 mm, 3.0 mm and 3.2mm. Mesh width of 25 to 200 mm (or bigger) are possible depending on cable diameter.
Rope Mesh is manufactured from high-grade stainless steel cables of material class 1.4401, AISI316.
Mesh connections (ferrules) are available in highly aesthetic stainless steel for premium applications or where resistance to corrosion is a driving consideration.
Finished diamond mesh style when it is stretched at 60 degree angle ;
Mesh can be applied in either a vertical or horizontal direction, again dependent on the balustrade or railing design and the required aesthetics.
X Tend Cable Mesh Specifications Sheet :
|
Hole Size (Opening) |
1.2MM(3/64) (7 x 7 ) |
1.6MM(1/16) (7 x 7 ) |
2.0MM(5/64) (7 x 7 ) |
2.4MM(3/32) (7 x 7 ) |
3.2MM(1/8) (7 x 19 ) |
| 20 x 35mm | YT-1235 | ||||
| 25 x 42mm | YT-1225 | YT-1625 | |||
| 30 x 52mm | YT-1230 | YT-1630 | YT-2030 | ||
| 35 x 60mm | YT-1235 | YT-1635 | YT-2035 | ||
| 38 x 66mm | YT-1238 | YT-1638 | YT-2038 | YT-2438 | |
| 40 x 69mm | YT-1240 | YT-1640 | YT-2040 | YT-2440 | YT-3040 |
| 50 x 86mm | YT-1250 | YT-1650 | YT-2050 | YT-2450 | YT-3050 |
| 60 x 104mm | YT-1260 | YT-1660 | YT-2060 | YT-2460 | YT-3060 |
| 70 x 120mm | YT-1270 | YT-1670 | YT-2070 | YT-2470 | YT-3070 |
| 76 x 131mm | YT-1276 | YT-1676 | YT-2076 | YT-2476 | YT-3076 |
| 80 x 138mm | YT-1280 | YT-1680 | YT-2080 | YT-2480 | YT-3080 |
| 90 x 154mm | YT-1290 | YT-1690 | YT-2090 | YT-2490 | YT-3090 |
| 100 x 173mm | YT-12100 | YT-16100 | YT-20100 | YT-24100 | YT-30100 |
| 120 x 206mm | YT-12120 | YT-16120 | YT-20120 | YT-24120 | YT-30120 |
Material of X Tend Cable Mesh
1. Material of Exhibition Flexible Ferrule Stainless Steel Wire Rope Mesh : Stainless steel 304,304L,316,306L etc.
2. Ferrules Material of Exhibition Flexible Ferrule Stainless Steel Wire Rope Mesh : Tinned-copper, Nickel-plated copper, Stainless steel etc.
3. Cable construction and Diameter of X-tend Cable Mesh : 7x7 (Dia.: 1.2 - 2.5mm), 7x19 (Dia.: 3.0 - 4.0mm)
| SS304 | (%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035 |
| SS316 | (%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5 |
| SS316L | (%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0 |
